SPI/MOTOROLA Verification IP provides an smart way to verify the serial synchronous communication protocol.The SmartDV's SPI/FLASH Verification IP is fully compliant with SPI Block Guide V04.01 of the Motorola's M68HC11 user manual rev 5.0 SPI-Bus Specification provides the following features. It can work with Verilog HDL environment and works with all Verilog simulators that are support SystemVerilog.
SPI/MOTOROLA Verification IP is supported natively in SystemVerilog, VMM, RVM, AVM, OVM, UVM, Verilog, SystemC, VERA, Specman E and non-standard verification env
SPI/MOTOROLA Verification IP comes with optional Smart Visual Protocol Debugger (Smart ViPDebug), which is GUI based debugger to speed up debugging.
- Features
-
- Follows MOTOROLA basic specification as defined in Motorola's M68HC11 user manual rev 5.0
- Support Master and Slave Mode
- Supports data width from 4bits upto 16bits
- Supports two SPI/MOTOROLA modes to control MOTOROLA device
- Support baud rate selection
- Support internal clock division check.
- Support clock polarity (CPOL) selections.
- Support clock phase (CPHA) selection.
- Support single and burst transfer mode.
- Support on the fly generation of data.
- Detects and reports the Mode Fault error
- Supports constraints Randomization.
- Glitch insertion and detection
- Built in functional coverage analysis.
- Status counters for various events on bus.
- Supports single,dual bus width operation
- Supports Callbacks in master, slave and monitor for modifying, and sampling data/cmd on MOTOROLA.
- MOTOROLA Slave can be configured as standard device or can use FIFO for data passing.
- Master contains rich set of commands for both standard device and FIFO model mode
- Benefits
-
- Faster testbench development and more complete verification of MOTOROLA designs.
- Easy to use command interface simplifies testbench control and configuration of slave and master.
- Simplifies results analysis.
- Runs in every major simulation environment.
- SPI Verification Env
-
SmartDV's SPI/MOTOROLA Verification env contains following.
- Complete regression suite containing all the SPI/MOTOROLA testcases.
- Examples showing how to connect various components, and usage of Master, Slave and Monitor.
- Detailed documentation of all class, task and function's used in verification env.
- Documentation contains User's Guide and Release notes.
