Low Latency DRAM Memory Model provides an smart way to verify the Low Latency DRAM component of a SOC or a ASIC. The SmartDV's Low Latency DRAM memory model is fully compliant with standard Low Latency DRAM Specification and provides the following features. Better than Denali Memory Models.
Low Latency DRAM Memory Model is supported natively in SystemVerilog, VMM, RVM, AVM, OVM, UVM, Verilog, SystemC, VERA, Specman E and non-standard verification env
Low Latency DRAM Memory Model comes with optional Smart Visual Protocol Debugger (Smart ViPDebug), which is GUI based debugger to speed up debugging.
- Features
-
- Supports Low Latency DRAM memory devices from all leading vendors.
- Supports 100% of Low Latency DRAM protocol standard Low Latency DRAM specification.
- Supports programmable clock frequency of operation.
- Supports 8 internal banks.
- Supports for all Mode registers programming.
- Supports Programmable Read latency and Row cycle time.
- Supports Address Multiplexing.
- Supports all the Low Latency DRAM commands as per the specs.
- Supports for Programmable burst lengths.
- Supports Data Mask for Write commands
- Checks for following
- Check-points include power on, Initialization and power off rules,
- State based rules, Active Command rules,
- Read/Write Command rules etc.
- All timing violations.
- Support for Power Down features.
- Support for Self Refresh features.
- Supports for DLL.
- Supports for ODT (On-Die Termination).
- Support all types of timing and protocol violation detection.
- Constantly monitors Low Latency DRAM behavior during simulation.
- Protocol checker fully compliant with Low Latency DRAM Specification.
- Models, detects and notifies the test bench of significant events such as transactions, warnings, timing and protocol violations.
- Built in functional coverage analysis.
- Supports Callbacks, so that user can access the data observed by monitor.
- Benefits
-
- Faster testbench development and more complete verification of Low Latency DRAM designs.
- Easy to use command interface simplifies monitor control and configuration.
- Simplifies results analysis.
- Runs in every major simulation environment.
- Low Latency DRAM Verification Env
-
SmartDV's Low Latency DRAM Verification env contains following.
- Complete regression suite containing all the Low Latency DRAM testcases.
- Examples showing how to connect and usage of Model.
- Detailed documentation of all class, task and function's used in verification env.
- Documentation also contains User's Guide and Release notes.
