DDR Memory Model provides an smart way to verify the DDR component of a SOC or a ASIC. The SmartDV's DDR memory model is fully compliant with standard DDR Specification and provides the following features. Better than Denali Memory Models.
DDR Memory Model is supported natively in SystemVerilog, VMM, RVM, AVM, OVM, UVM, Verilog, SystemC, VERA, Specman E and non-standard verification env
DDR Memory Model comes with optional Smart Visual Protocol Debugger (Smart ViPDebug), which is GUI based debugger to speed up debugging.
- Features
-
- Supports DDR memory devices from all leading vendors.
- Supports 100% of DDR protocol standard JESD79F.
- Supports all the DDR commands as per the specs.
- Supports all device speeds as per specification.
- Supports Programmable CAS latency.
- Supports Programmable burst lengths: 2,4 and 8.
- Supports Write data Mask.
- Supports the following devices.
- Supports upto 1 GB device density.
- Supports the following burst types.
- Supports burst order.
- Supports for All Mode registers programming.
- Supports for Extended Mode registers programming.
- Supports Auto refresh & self refresh modes.
- Supports Auto precharge option for each burst access.
- Supports Power Down features.
- Supports input clock stop and frequency change.
- Supports DLL operation.
- Checks for following
- Check-points include power up, initialization and power off rules
- State based rules, Active Command rules
- Read/Write Command rules etc.,
- All timing violations
- Supports callbacks for user to get command data on bus.
- Quickly validates the implementation of the DDR standard JESD79F.
- Bus-accurate timing for min, max and typical values.
- Constantly monitors DDR behavior during simulation.
- Protocol checker fully compliant with DDR Specification JESD79F.
- Model, detects and notifies the test bench of significant events such as transactions, warnings, timing and protocol violations.
- Built in functional coverage analysis.
- Supports Callbacks, so that user can access the data observed by monitor.
- Benefits
-
- Faster testbench development and more complete verification of DDR designs.
- Easy to use command interface simplifies monitor control and configuration.
- Simplifies results analysis.
- Runs in every major simulation environment.
- DDR Verification Env
-
SmartDV's DDR Verification env contains following.
- Complete regression suite containing all the DDR testcases.
- Examples showing how to connect and usage of Model.
- Detailed documentation of all class, task and function's used in verification env.
- Documentation also contains User's Guide and Release notes.
