USB PD IIP

USB PD IIP

USB PD interface provides full support for the USB PD synchronous serial interface, compatible with USB 3.1/3.0/2.0 and 1.0 specifications. Through its USB PD compatibility, it provides a simple interface to a wide range of low-cost devices. USB PD IIP is proven in FPGA environment. The host interface of the USB PD can be simple interface or can be AMBA AHB, AMBA AXI, VCI, OCP, Avalon, PLB, Tilelink, Wishbone or Custom protocol.

USB PD IIP is supported natively in Verilog and VHDL

Features
  • Compliant with USB Power Delivery Specification 3.1/3.0/2.0 and 1.0
  • Supports Cable plug communication
  • Supports all Resets: Hard, Soft and Cable Resets
  • Supports all types of packets.
  • Supports BFSK and BMC signaling of physical layer
  • Support BIST.
  • Supports Timers as per specification
  • Supports Counters as per specification
  • Supports data role swap and power role swap
  • Supports Structured and Unstructured VDM
  • Supports Device and System Policy
  • Supports injecting timing variations in physical layer.
  • Supports all Swappings: Power role, Data role, Fast power role and Vconn swap
  • Supports chunked transaction
  • Supports included extended power supply capabilities and status.
  • Fully synthesizable.
  • Static synchronous design.
  • Positive edge clocking and no internal tri-states.
  • Scan test ready.
  • Simple interface allows easy connection to microprocessor/microcontroller devices.
Benefits
  • Single Site license option is provided to companies designing in a single site.
  • Multi Sites license option is provided to companies designing in multiple sites.
  • Single Design license allows implementation of the IP Core in a single FPGA bitstream and ASIC.
  • Unlimited Designs, license allows implementation of the IP Core in unlimited number of FPGA bitstreams and ASIC designs.
Deliverables

    Note: Only mails from offical mail ID will be processed

    Request Datasheet
    Request Evaluation

    SmartDV's USB PD IP contains following

  • The USB PD interface is available in Source and netlist products.
  • The Source product is delivered in verilog. If needed VHDL, SystemC code can also be provided.
  • Easy to use Verilog Test Environment with Verilog Testcases
  • Lint, CDC, Synthesis, Simulation Scripts with waiver files
  • IP-XACT RDL generated address map
  • Firmware code and Linux driver package
  • Documentation contains User's Guide and Release notes.
