H265 Encoder core is compliant with standard ISO/IEC 23008-2/ITU-T H.265 specification. Through its compatibility, it provides a simple interface to a wide range of low-cost devices.H265 Encoder IIP is proven in FPGA environment. The host interface of the H265 can be simple interface or can be AHB, AHB-Lite, APB, AXI, AXI-Lite, Tilelink, OCP, VCI, Avalon, PLB, Wishbone or custom buses.
H265 ENCODER IIP is supported natively in Verilog and VHDL
- Features
-
- Supports ISO/IEC 23008-/ITU-T H.265 specification.
- Supports full H.265/HEVC Encoder functionality.
- Supports profile level up to 6.2.
- Supports resolution up to 3840x2160@60fps.
- Supports adaptive deblocking and sample adaptive offset filters.
- Supports CABAC entropy coding.
- Supports all prediction methods,
- Inter prediction
- Intra prediction
- Supports 32x32, 16x16, 8x8 and 4x4 integer DCT Transform
- Supports Chroma 4:4:4, 4:2:2 and 4:2:0
- Supports VBR and CBR.
- Fully synthesizable
- Static synchronous design
- Positive edge clocking and no internal tri-states
- Scan test ready
- Simple interface allows easy connection to microprocessor/microcontroller devices
- Supports 8bpp,10bpp and 12bpp color modes
- Supports input pixels at 1/2/4/8 pixel per clock
- Supports 8,10,16,20,32 bits output bit stream
- Benefits
-
- Single site license option is provided to companies designing in a single site.
- Multi sites license option is provided to companies designing in multiple sites.
- Single Design license allows implementation of the IP Core in a single FPGA bitstream and ASIC.
- Unlimited Designs, license allows implementation of the IP Core in unlimited number of FPGA bitstreams and ASIC designs.
- Deliverables
-
SmartDV's H265 Encoder IP contains following
- The H265 Encoder interface is available in Source and netlist products.
- The Source product is delivered in plain text verilog. If needed VHDL,SystemC code can also be provided.
- Easy to use Verilog Test Environment with Verilog Testcases
- Lint, CDC, Synthesis, Simulation Scripts with waiver files
- IP-XACT RDL generated address map
- Firmware code and Linux driver package
- Documentation contains User's Guide and Release notes.
