Serial flash memory model is the serial synchronous communication protocol based Flash memory model, supporting all major Serial flash memory vendors. Serial Flash memory model can be used to verify serial flash controller in SOC. It can work with Verilog HDL environment and works with all Verilog simulators that are support SystemVerilog.
Serial Flash Memory Model
is supported natively in SystemVerilog, VMM, RVM, AVM, OVM, UVM, Verilog, SystemC, VERA, Specman E and non-standard verification env
Serial Flash Memory Model
comes with optional Smart Visual Protocol Debugger (Smart ViPDebug), which is GUI based debugger to speed up debugging.
- Features
-
- Follows Serial Flash specification as defined in WINBOND, MICRONIC, MACRONIX, MICRON, SPANSION, Silicon Storage technology (SST) and many more.
- Supports software and hardware Reset
- Supports quad peripheral interface (QPI) reduces instruction overhead
- Supports allows true XIP (execute in place) operation
- Supports program 1 to 256 byte per programmable page
- Supports erase/program suspend & resume
- Supports software and hardware write-protect
- Supports discoverable parameters (SFDP) register
- Supports volatile & non-volatile Status Register Bits
- Supports advanced security features
- Supports 3-wire,4-wire interface
- Supports baud rate selection
- Supports burst modes
- Supports fast read and byte program
- Supports block/sector protection
- Supports flexible erase operation like,
- 4KByte sector erase
- 32KByte block erase
- 64KByte block erase
- Supports internal clock division check
- Supports security ID
- Supports on the fly generation of data
- Supports backdoor initialization of data
- Supports constraints Randomization
- Built in functional coverage analysis
- Supports Callbacks in controller, memory model and monitor for modifying, and sampling data/cmd on bus.
- Notifies the test bench of significant events such as transactions, warnings, and protocol violations. This can be written to separate log files.
- Serial Flash Verification IP comes with complete testsuite to test every feature of Serial Flash specification
- Benefits
-
- Faster testbench development and more complete verification of Serial Flash designs.
- Easy to use command interface simplifies testbench control and configuration of slave and master.
- Simplifies results analysis.
- Runs in every major simulation environment
- Serial Flash memory model Verification Env
-
SmartDV's Serial flash model Verification env contains following.
- Complete regression suite containing all the serial flash memory testcases.
- Examples showing how to connect various components, and usage of controller, serial flash model and Monitor.
- Detailed documentation of all class, task and function's used in verification env.
- Documentation contains User's Guide and Release notes.
